Features:

Fastest in-line repair - Repairable in line more easily and at less cost than other similar valve. Stem, disc, and packing can be quickly removed through the yoke, and the seat fully exposed for "like new" restoration.

High dependability - One-piece forged body without pressure welds, seal welds, pressure-containing threads or gaskets, body/bonnet joints, or any of their related problems.

Greater durability - Solid Stellite? disc and seat ring all but eliminates cracking. Extra thickness of the seat ring also provides enough material to renew the seating surface over and over again.

High flow capacity - Generous port sizes and disc retraction well beyond that required for optimum flow. These features help to minimize flow velocities, and therefore, decrease the erosive forces, which shorten the life of the seat and disc.

Available off-the-shelf - An in-depth stocking program makes Welbond? valves available to you directly off-theshelf (socketweld ends standard to NPS 2?).

Convertible feature - The complete premachining of each valve body means one of the backseat designs can be converted to the other, simply by reassembly with alternate backseat bushing.

Specifications:

Certifications PED, India Boiler Registration, ASME B31.1, CE

End Connection Butt Weld

Application High Temp, General Service, Cogeneration, Boilers, Boiler, Biomass Boiler and Power Boiler, Balance of Plant, HRSG, Pumps, Valves & Manifolds, Clean Steam, Waste to Energy, Steam turbine

Body Design Long Pattern

Material Steel, Carbon Steel

Operating Temperature High Temperature, Greater Than 400 F (204 C)

Pressure Class ASME

Process Connection Type BWE

Seat/Seal Type Metal-to-Metal

Shutoff Class Class V (FCI 70-2)

Standards ASME B16.34

Style Globe Valves

Valve Size NPS 2-1/2 / DN 65, NPS 3 / DN 80, NPS 2 / DN 50, NPS 1-1/4 / DN 32, NPS 1-1/2 / DN 40, NPS 1/2 / DN 15, NPS 1 / DN 25

Valve Size Standard NPS

Valve Type Globe
