Features:

PFA lining offers highest corrosion resistance

Bubble tight shut-off: precision machined ball and seats -guarantees an absolute leak-free valve.

Full bore offers high Kv-value equal to the pipe

One-piece ball/stem: no possibility of damaging PFA-lining on ball by the stem, no hysteresis, ideal for flow control applications.

Specific anti blow-out shaft design, which can not be affected by the media, according API 609.

Static electricity: any build-up of static electricity is -eliminated since the ball/stem and the housing are of the same potential.

Constant torque: the unique two-piece body construction together with the spring loaded seats guarantee a constant torque even after months of operation. TA-Luft VDI 2440 approved.

The self adjusting packing is maintenance free and provides a leak free stem seal.

The handlever features a positive locked position in the open and closed position for type NTB, and 6 intermediate positions for type NTC.

The body has a thermally applied polyester powder coating (RAL 9002) which offers excellent protection against external corrosion and rust.

Direct mounting according to ISO 5211.

Specifications:

Certifications CE, CRN, CUTR, Fugitive Emission, PED

End Connection Flanged

Body Design Long Pattern, Short Pattern

Material 316 Stainless Steel, Ductile Iron

Operating Temperature Less Than 200 C

Pressure Class PN

Process Connection Type 150RF, PN16

Seat/Seal Type Lined

Valve Size NPS 3 / DN 80, NPS 4 / DN 100, NPS 6 / DN 150, NPS 2 / DN 50, NPS 1 / DN 25, NPS 3/4 / DN 20, NPS 1-1/2 / DN 40, NPS 1/2 / DN 15

Valve Size Standard DN

Valve Type Ball Valve

Media Aggressive Liquids/Gases
