Features:

One piece reduced bore body, flanged construction in carbon steel, stainless steel and special alloys.

Compact body design with minimum weight and elimination of potential leak path.

Designed in accordance with ASME B16.34, BS EN ISO 17292 and ISO 14313/API 6D.

Floating ball design for bi-directional shut-off.

Flexing soft seat design for superior shut-off across a range of pressures with minimum operating torque.

Low temperature and cryogenic designs for service down to -196°C available on request.

Spring energized metal and carbon seat designs permitting tight shut-off and positive cavity pressure relief.

Fused hard nickel alloy, chromium carbide or tungsten carbide coated seat and ball designs for abrasive and high temperature service.

Hard carbon seat design for medium temperature applications.

High integrity shaft seal minimizing the potential for atmospheric leakage.

Fugitive emission performance to BS EN ISO 15848-2 class A.

Corrosion resistant trim. Standard valves incorporate balls and shafts of stainless steel for long service life.

Specifications:

Certifications ABS, cRU, Fire Safe, American Bureau of Shipping Shipboard, Fugitive Emission, NACE, PED, SIL capable

End Connection Flanged

Application Steam Headers, Storage & Distribution, Storage & Transport, Storage and Distribution, Storage, Refining, Cooling Water

Body Design Side Entry, Long Pattern, Short Pattern

Material Super Duplex, Stainless Steel, Stainless, Monel, Inconel, Hastelloy

Pressure Class ASME

Process Connection Type CL300RF, CL150RF, 300RF, 150RF

Seat/Seal Type Ball, Cryogenic, Metal, Soft, Soft Seal

Shutoff Class Class VI (FCI 70-2), API 598, Zero Leakage

Standards API 608, ASME B16.34

Valve Size NPS 14 / DN 350, NPS 2 / DN 50, NPS 3 / DN 80, NPS 3/4 / DN 20, NPS 4 / DN 100, NPS 6 / DN 150, NPS 8 / DN 200, NPS 12 / DN 300

Valve Size Standard DN, NPS

Valve Type Ball, Floating Ball Valve, Ball Valve

Media Water, Vacuum, Steam, Specialty Gases, Oxygen
